Wood processing multiple spindle moulding shaper machine woodworking four side planer moulder | Four Side Moulder
Model:MB412
Max.Planing Depth(mm):80 mm
Max planing width:120mm
Maximum processing length:6000mm
Knife shaft speed:8500r/min
Spindle diameter:30mm
Weight (KG):350 KG
Power (kW):12
Max.Planing Depth(mm):80 mm
Max planing width:120mm
Maximum processing length:6000mm
Knife shaft speed:8500r/min
Spindle diameter:30mm
Weight (KG):350 KG
Power (kW):12
Details
Spare Parts
Inquiry
12-230 mm width moulding capacity(different model with different working size). Full coverage sound cover/safety enclosure is optional. Long infeed table and fence for straightening. Precision sealed long life bearing. Industrial full power motor for maximum cutting capacity. High quality famous brand electric parts.
|
Produce name
|
Four side planer shaper woodworking machine
|
|
Model
|
MB412
|
|
Minimum processing length
|
250mm
|
|
Maximum processing length
|
6000mm
|
|
Minimum processing width
|
10mm
|
|
Maximum processing width
|
120mm
|
|
Minimum processing thickness
|
8mm
|
|
Maximum processing thickness
|
60mm
|
|
Knife shaft speed
|
8500r/min
|
|
The maximum loading diameter
|
ø100mm
|
|
Feed power
|
1.5KW
|
|
Feed speed
|
6-30m/min
|
|
First lower spindle
|
3KW
|
|
First upper spindle
|
4KW
|
|
Lifting motor power
|
0.37kw
|
|
Spindle motor power
|
5.5kw
|
|
Total power
|
12.87KW
|
|
Spindle diameter
|
ø30mm
|
4 head Moulder Solid steel construction for long life and vibration free performance. Incorporates many outstanding featurres including high speed operation and superior accuracy.
Industrial full power motor for maximum cutting capacity. High quality famous brand electric parts.
Working table surface adopts special materials and special heat treatment, hard chrome plating is thicker than others, wear-resistance, ensure 4 head moulder working table long time using.
Finished four side processing by one pass through feeding, Wood multiple Spindle For Sale 4 Head Moulder is convinient and safety machines.
4 head mouldercombines high efficiency with heavy duty operation and comes with a sound reputation for maximum dependability.
Industrial full power motor for maximum cutting capacity. High quality famous brand electric parts.
Working table surface adopts special materials and special heat treatment, hard chrome plating is thicker than others, wear-resistance, ensure 4 head moulder working table long time using.
Finished four side processing by one pass through feeding, Wood multiple Spindle For Sale 4 Head Moulder is convinient and safety machines.
4 head mouldercombines high efficiency with heavy duty operation and comes with a sound reputation for maximum dependability.
WEHO Machinery is an original equipment manufacturer, all machines can be custom built to the customer requirements. We can design and manufacture most of wood processing machines. Our goal is to exceed customer expectations. We’re machine factory, but service is our business.
