three UV Light Lamp Gel Curing Dryer Machine for Furniture/Glass/PVC | Uv Light Lamp Dryer Machine
Quick Details
Model：600 900 1300
Processing length range (max, min)： Min300mm Min300mm Min300mm
Processing width range (max, min)：Max600mm Max900mm Max1300mm
Machining thickness range (max, min)：3-80mm 3-80mm 3-80mm
Feeding speed：0-20m/min 0-20m/min 0-20m/min
Feeding speed：0.4kw 0.75kw 0.75kw
Lugs power：5kw 8kw 11kw
Model：600 900 1300
Processing length range (max, min)： Min300mm Min300mm Min300mm
Processing width range (max, min)：Max600mm Max900mm Max1300mm
Machining thickness range (max, min)：3-80mm 3-80mm 3-80mm
Feeding speed：0-20m/min 0-20m/min 0-20m/min
Feeding speed：0.4kw 0.75kw 0.75kw
Lugs power：5kw 8kw 11kw
Details
Spare Parts
Inquiry
Widely used to dry flat articles which are coated by UV coagulated paint.The inside of the lamp house module enjoys good aeration, which prolongs the working life of UV lamps, transducers and capacitor glass uv light lamp dryer machine.The three UV lamp dryer machine for furniture well-designed structure of conveyor prolongs the life of the belt and ensures the brightness of the painted workpieces.
Imported gallium lamps can be selected to dry solid UV curing paints. Optional Distribution of Electronic Power Supply.
The dry machine for gel inlet/outlet shading boards are furnished with anti-UV isolation boards to effectively prevent UV leakage.
| Model | 600 | 900 | 1300 |
| Processing length range (max, min) | Min300mm | Min300mm | Min300mm |
| Processing width range (max, min) | Max600mm | Max900mm | Max1300mm |
| Machining thickness range (max, min) | 3-80mm | 3-80mm | 3-80mm |
| Feeding speed | 0-20m/min | 0-20m/min | 0-20m/min |
| Feeding speed | 0.4kw | 0.75kw | 0.75kw |
| Lugs power | 5kw | 8kw | 11kw |
| Temperature range | 60-120° | 60-120° | 60-120° |
| Installed power of the whole machine | 13.45kw | 18kw | 24.25kw |
| Package size | 2000*1100*1750mm | 2000*1400*1750mm | 2000*1800*1750mm |
WEHO Machinery is an original equipment manufacturer, all machines can be custom built to the customer requirements. We can design and manufacture most of wood processing machines.Our goal is to exceed customer expectations. We’re machine factory, but service is our business.
